Land Pride SG2584

Double tap to zoom

FEATURES	BENEFITS
Skid steer mounting plate.	Fits most/all skid steer front loader hitches.
40-95 hp requirements.	Makes it compatible with many popular smaller sized skid steers and tractors in use today.
Dual adjustable height grader blades.	Allows the grader to be adjusted to desired amount of cultivation, leveling, and grading action.
3-Position scarifier shanks.	Allows shanks to be adjusted to two depths or above ground.
Ripping-Only Functionality	Frame geometry gives the user the option to solely use straight shanks, reducing horsepower requirements when the surface requires multiple ripping passes.
Reversible heat treated high carbon steel grading blades.	For excellent wear resistance and long service life.
Hardened straight shanks.	Assures long service life.
Full length heavy duty skid shoes.	Makes for easier operation and long unit life.
Replaceable and reversible skid shoes.	Extends the life of the skid shoes.
Heavy duty frame construction.	Assures long lasting reliability and performance.

Model	AP-SG2584
Working width in (m)	84 (2.13)
Overall width in (m)	93 1/4 (2.37)
Number of straight shanks	7
Skid steer & tractor hp requirement hp (kW)	40-95 (29.8-70.8)
Unit weight with shanks lbs (kg)	952 (431.8)
Overall length in (m)	52 1/4 (1.33)
Overall height in (m)	22 (55.9)
Side panel height with skid shoes in (m)	15 1/2 (39.4)
Side panel length in (m)	50 (1.27)
Side panel thickness in (m)	1/4 (6) Thick with 2 3/4 (70) formed edges.
Skid shoe construction in (m)	3/8 (10) Thick with a formed bevel to prevent gouging.
Straight shank construction in (m)	Heat-treated 3-position shank.
Cutting edges in (m)	Four 1/2 x 6 (1.3 x 15.2) high-carbon, heat-treated blades that are reversible and replaceable.
Cutting edge adjustment in (m)	Variable vertical adjustment from level grade to 1 1/2 (3.8) below grade.
Shank adjustments in (m)	2 1/2 (64) and 3/4 (19) below grade level. 3/4 (19) above grade level.
Hitch type	Skid steer mounting plate
