Land Pride SG2572

Double tap to zoom

Features	Benefits
Skid steer mounting plate.	Fits most/all skid steer front loader hitches.
40-95 hp requirements.	Makes it compatible with many popular smaller sized skid steers and tractors in use today.
Dual adjustable height grader blades.	Allows the grader to be adjusted to desired amount of cultivation, leveling, and grading action.
3-Position scarifier shanks.	Allows shanks to be adjusted to two depths or above ground.
Ripping-Only Functionality	Frame geometry gives the user the option to solely use straight shanks, reducing horsepower requirements whenthe surface requires multiple ripping passes.
Reversible heat treated high carbon steel grading blades.	For excellent wear resistance and long service life.
Hardened straight shanks.	Assures long service life.
Full length heavy duty skid shoes.	Makes for easier operation and long unit life.
Replaceable and reversible skid shoes.	Extends the life of the skid shoes.
Heavy duty frame construction.	Assures long lasting reliability and performance.

Model Numbers	AP-SG2572
Working width	72"
Overall width	81 1/4"
Number of straight shanks	6
Skid steer & tractor hp requirement	40-95 hp
Unit weight with shanks	886 lbs.
Overall length	52 1/2"
Overall height	22"
Side panel height with skid shoes	15 1/2"
Side panel length	50"
Side panel thickness	1/4" Thick with 2 3/4" formed edges.
Skid shoe construction	3/8" Thick with a formed bevel to prevent gouging.
Straight shank construction	Heat-treated 3-position shank
Cutting edges	Four 1/2" x 6" high-carbon, heat-treated blades that are reversible and replaceable
Cutting edge adjustment	Variable vertical adjustment from level grade to 1 1/2" below grade.
Shank adjustments	2 1/2" and 3/4" below grade level; 3/4" above grade level
Hitch type	Skid steer mounting plate
