Land Pride SC2572 » Roeder Implement Inc., Iowa

Double tap to zoom



Features

Low volume motor @ 11-17 gpm
Medium volume motor @ 18-23 gpm
High volume motor @ 24-30 gpm
Customer can choose one of three optional motors for his SC2560 cutter or one of three optional motors (low, medium and high volume) for his SC2572 cutter. This allows the cutter to fit a wide variety of Skid Steers. Also the deck can be upgraded to a different motor when owner upgrades his Skid Steer
Case drain Protects gearbox.
1/4" Side panels for overall reinforcement Protects sides from debris being thrown against them from the blades.
Front and rear chain shields Single chain on the front and double chain on the rear. Reduces flying debris.
Replaceable skid shoes (optional) Protect side plate structure. Shoes are replaceable for convenience.
Splined blade bar Allows for tight positive fit of stump jumper and blade bar to motor output shaft.
3/16" Round stump jumper Standard stump jumper aids in sliding over obstructions, which helps protect gearbox output shaft.
1/2" x 4" Heat-treated free swinging blades Heat-treated blades offer longer life. Free-swinging blades protect from obstructions
2" Diameter cutting capacity Can aid in clearing brush.
SC2572 High blade tip speed Medium volume motor = 19,487 fpm at 23 gpm.
High volume motor = 19,685 fpm at 30 gpm.
Offset hitch (8 1/2" to the right) Allows the operator to cut close to obstacles on the right side.
Optional front gauge wheel Provides easy operation and handling over uneven terrain, laminated tire can’t go flat.
Floating hitch mounting plate Allows smoother travel over rough terrain with the optional gauge wheel easing the fatigue put on the operator
Motor pressure gauge Allows the operator to ensure that the motor is operating at proper psi.
Lift limit safety chain Provides additional operator protection from flying objects by allowing the Rotary Cutter to only be lifted up to 18".

Specifications

Model Numbers SC2572
Cutter weight without skid shoes, gauge wheel, & protective door 1098 lbs (498.0 kg)
Gauge wheel weight (Optional) 129 lbs (58.5 kg)
Skid shoe weight (Optional) Standard skid shoes = 10 lbs (4.5 kg)
Heavy-duty skid shoes = 21 lbs (9.5 kg)
Protective door weight (Optional) 10 lbs (4.5 kg)
Hitch Universal floating-hitch mounting plate. Hitch plate can be mounted centered on the deck or mounted to offset the deck to the right 8 1/2" (21.6 cm).
Cutting width 72" (1.83 m)
Overall width 78" (1.98 m)
Overall length 91" (2.31 m)
Cutting height 1 1/2" to 18" (3.8 cm to 45.7 cm) infinitely variable.
Cutting capacity 2" (5.1 cm) Diameter
Gearbox oil capacity & lubrication 6 Pints (2.84 L) of EP 80-90 wt. gearlube
Spindle hub oil Does not apply
Low volume drive motor 11-17 gpm (41.6-64.4 lpm) flow
Medium volume drive motor 18-23 gpm (68.1-87.1 lpm) flow
High volume drive motor 24-30 gpm (90.8-113.6 lpm) flow
Hydraulic pressure 1500 to 3500 psi (10.34 to 24.13 MPa)
Deck thickness 10 Ga. (3.4 mm)
Side skirt construction 1/4" (6 mm) Steel
Deck wear protection (Optional) Optional four corner mounted skid shoes
Skid shoes construction (Optional) Standard-duty skid shoes = 1/4" x 2" (6 mm x 5.1 cm) steel
Heavy-duty skid shoes = 3/8" x 3" (1 cm x 7.6 cm) steel
Dishpan Heavy duty round pan stump jumper.
Blade size 1/2" x 4" (1.3 cm x 10.2 cm) updraft
Blade rotation Clockwise
Blade Bolt 1 1/8"-12 x 3 7/16" with key
11-17 gpm motor blade tip speed
18-23 gpm motor blade tip speed
24-30 gpm motor blade tip speed
N/A
14,199 fpm at 23 gpm
15,707 fpm at 30 gpm
Front deck protection Single row chain guard.
Rear deck protection Double row chain guard.
Deck lift height protection Safe chain limiter
Cutting height gauging (Optional) Pivoting and adjustable front mounted gauge wheel with laminated tire
